| Charging interface type | GBT to Type 2 |
|---|---|
| Rate Current | 32A, 1/3 phase |
| Rate Voltage | 220V-250V;380V-450V |
| Inflammability Rating | UL94 v-0 |
| Insulation resistance | 0.5mΩ Max |
| Mating and UN-Mating Force | 45N<F<80N |
| Mechanical Life(Normal use) | >10000 times |
| Working Temperature | -30°C~+50°C |
| Shell | Thermoplastic material |
| Connector Pin | Copper alloy,silver plating |
